Cotton Picker Radial Tyre



Agricultural cotton picker radial tyres are a kind of specially designed tyres specifically for cotton picker equipment, due to the need to adapt to different terrain and climate conditions when the cotton picker is in operation, especially during the cotton ripening season, it may encounter wet mud, soft ground or other complex ground conditions. Therefore, the radial structure design and special tread pattern design used in this type of tyre enable it to provide a larger grounding area when contacting the ground, thus reducing compaction on the soil, and at the same time increasing the grip and abrasion resistance of the cotton picker, so as to ensure that the machine can be operated stably during operation, improve operational efficiency, and reduce damage to the cotton.





1. Great traction. The tread pattern shape, angle, number and depth of the cotton picker radial tyres are carefully designed to ensure that the tyres have great traction in all soil conditions;

2. Good abrasion resistance. The larger tread end in the center of the tread gives the tyre excellent abrasion resistance, which is especially important for operating in harsh farmland environments;

3. Low soil compaction. The special tread design of the cotton picker radial tyre helps to distribute the pressure and contributes to low soil compaction, thus ensuring permeability and fertility of the soil;

4. Excellent self-cleaning ability. The large contact area of the tread reduces damage to the soil and crops, while providing excellent self-cleaning, which is important for maintaining healthy crop growth;

5. Long service life. Because the structural design and material selection of cotton picker radial tyres are designed to increase durability, they typically have a long service life;

6. High safety. As the structural design of radial tyres makes them more stable when rolling, the risk of rollover is reduced, thus making the cotton picker safer during operation;

7. Strong durability. Cotton picker radial tyres are made of high-strength materials that are more abrasion- and puncture-resistant than bias-ply tyres, which means they are more likely to remain intact in harsh farmland environments for a longer service life.





AR2000 Size	Load Index	Speed Rating	Type	Pattern Code	Section Width (mm)	Overall Diameter (mm)	Maximum Speed (km/h)	Inflation Pressure(kPa)	Maximum Load (kg)	Standard Rim	Tread Depth (mm)
IF380/90R46	160	D	TL	R-1W	383	1852	65	300	4500	W13	45.0
IF380/90R54	171	D	TL	R-1W	383	2056	65	440	6150	W13	45.0
IF520/85R42	169	A8	TL	R-1W	526	1951	40	240	5800	DW18L	54.0
IF580/80R34	177	A8	TL	R-1W	586	1792	40	360	7300	DW20B	55.0
IF710/75R42	181	D	TL	R-1W	716	2133	65	240	8250	DW25B	63.0
IF600/70R28	164	D	TL	R-1W	603	1551	65	240	5000	DW21B	54.0
IF600/70R28	177	A8	TL	R-1W	603	1551	40	400	7300	DW21B	54.0
IF600/70R30	159	D	TL	R-1W	603	1602	65	160	4375	DW21B	54.0
IF710/70R42	179	D	TL	R-1W	705	2061	65	240	7750	DW25B	62.0
IF800/70R38	179	D	TL	R-1W	804	2085	65	160	7750	DW27B	62.0
IF800/70R38	184	D	TL	R-1W	804	2085	65	240	9000	DW27B	62.0
IF800/70R38	187	D	TL	R-1W	804	2085	65	280	9750	DW27B	62.0
IF800/70R38	190	D	TL	AR2000	804	2085	65	320	10600	DW27B	62.0
IF710/60R38	166	D	TL	R-1W	708	1817	65	160	5300	DW25B	54.0
IF710/60R38	172	D	TL	R-1W	708	1817	65	240	6300	DW25B	54.0
IF710/60R34	164	D	TL	R-1W	708	1716	65	160	5000	DW25B	54.0
IF710/60R34	170	D	TL	R-1W	708	1716	65	240	6000	DW25B	54.0
IF1050/50R32	185	D	TL	R-1W	1058	1863	65	240	9250	36.00VA	58.0





● Agricultural tyres are defined as tyres that are specifically used for agricultural machinery and are resistant to abrasion, punctures, high temperatures and other characteristics. According to the tyre carcass structure and purpose, agricultural tyres can be classified into agricultural radial tyres, agricultural bias tyres, agricultural implement tyres and agricultural construction machinery tyres. These tyres are designed to adapt to a variety of terrains, such as mud, sand, dry fields, paddy fields, etc., and are used on agricultural machinery, such as tractors, harvesters, etc..



● Agricultural radial tyres are also called wire tyres. These tyres generally have two or three layers of steel wire ring belt cross placed on the cord fabric carcass combination. Agricultural radial tyres are characterized by durability and puncture resistance, as well as high load capacity and good shock absorption. When the vehicle is in operation, this kind of tyre is not easy to appear deformation, so it can reduce fuel consumption to a certain extent, with good economy. In addition, its heat dissipation performance is also very good, more suitable for high temperature, high speed agricultural machinery use.
