Product Information

Agricultural tractor radial tyres are a kind of tyres specially designed for agricultural tractors. Due to its radial rubber formula and structural design, it has good abrasion and puncture resistance, low rolling resistance, high load carrying capacity, good side-slip resistance and long service life in order to adapt to the special needs of farmland operation.

R-1W series radial agricultural tyres are designed and produced with special materials and formulas,which not only specially designed the tyre thead and sidewall,but also improved the production formula.These changes give it strong traction,self-cleaning,load force,and excellent wear resistance.Unique pattern design ensure its high traction and stability under various soil conditions.The operation comfort and stability of agricultural machinery are improved.They are mainly suitable for agricultural tractors for dry-field operation and short-distance field transportation.

Product Advantages

1. Strong load capacity. Radial tyres are able to withstand large loads, suitable for tractors and other heavy agricultural machinery. At the same time, the ground profile of the tyre has low compaction of the soil, which is beneficial to the growth of crops;

2. Reduced fuel consumption. Due to the structural characteristics of radial tyres, the tractor radial tyres are not easy to deform in the process of driving, thus reducing rolling resistance and effectively reducing fuel consumption;

3. Abrasion and puncture resistance. The tread rubber is specially formulated with excellent cut, puncture and abrasion resistance, which provides an inherent structural advantage for use in harsh environments;

4. Excellent traction and self-cleaning. The tread has a larger contact area with the ground for better traction, enabling the tractor to climb better and overcome various terrains;

5. Excellent shock absorption and driving stability. Tractor radial tyres have good shock absorption properties that help protect the tractor from uneven road surfaces. Meanwhile, the unique tread design of the tread helps to reduce side slip phenomenon and improve driving stability;

6. Extend tyre life. Tractor radial tyres last longer due to superior control of materials and quality;

7. Good weather aging resistance;

8. Premium rubber formulation to minimize ozone cracking and aging.

Product Specifications

R-1W Size	Load Index	Speed Rating	Type	Pattern Code	Section Width (mm)	Overall Diameter (mm)	Maximum Speed (km/h)	Inflation Pressure(kPa)	Maximum Load (kg)	Standard Rim	Tread Depth (mm)
14.9R26	127	A8/B	TL	R-1W	378	1316	40/50	160	1750	W13	47.0
14.9R26	132	A8/B	TL	R-1W	378	1316	40/50	210	2000	W13	47.0
14.9R30	129	A8/B	TL	R-1W	378	1400	40/50	160	1850	W13	46.0
15.5R38	134	A8/B	TL	R-1W	394	1569	40/50	160	2120	W14L	35.0
18.4R42	148	A8/B	TL	R-1W	467	1850	40/50	160	3150	DW16L	52.0
320/90R46	148	A8/B	TL	R-1W	319	1744	40/50	360	3150	W10	40.0
320/90R50	150	A8/B	TL	R-1W	319	1846	40/50	360	3350	W10	40.0
320/90R54	151	A8/B	TL	R-1W	319	1948	40/50	360	3450	W10	40.0
380/90R46	149	A8/B	TL	R-1W	380	1852	40/50	240	3250	W12	48.0
420/90R30	147	A8/B	TL	R-1W	418	1518	40/50	240	3075	W13	48.0
280/85R20	112	A8/B	TL	R-1W	282	984	40/50	160	1120	W9	40.0
280/85R24	115	A8/B	TL	R-1W	282	1086	40/50	160	1215	W9	43.0
320/85R24	122	A8/B	TL	R-1W	319	1154	40/50	160	1500	W10	44.0
320/85R28	124	A8/B	TL	R-1W	319	1255	40/50	160	1600	W10	44.0
340/85R24	125	A8/B	TL	R-1W	343	1188	40/50	160	1650	W11	45.0
340/85R28	127	A8/B	TL	R-1W	343	1293	40/50	160	1750	W11	45.0
380/85R24	131	A8/B	TL	R-1W	380	1256	40/50	160	1950	W12	46.0
380/85R28	133	A8/B	TL	R-1W	380	1357	40/50	160	2060	W12	46.0
380/85R30	135	A8/B	TL	R-1W	380	1408	40/50	160	2180	W12	47.0
380/85R34	137	A8/B	TL	R-1W	380	1510	40/50	160	2300	W12	47.0
380/85R34	142	A8/B	TL	R-1W	380	1510	40/50	240	2650	W12	47.0
420/85R24	137	A8/B	TL	R-1W	418	1324	40/50	160	2300	W15L	48.0
420/85R28 (16.9R28)	139	A8/B	TL	R-1W	418	1425	40/50	160	2430	W15L	48.0
420/85R28 (16.9R28)	144	A8/B	TL	R-1W	418	1425	40/50	240	2800	W15L	48.0
420/85R30 (16.9R30)	140	A8/B	TL	R-1W	418	1476	40/50	160	2500	W15L	48.0
420/85R34	142	A8/B	TL	R-1W	418	1578	40/50	160	2650	W15L	48.0
420/85R34	147	A8/B	TL	R-1W	418	1578	40/50	240	3075	W15L	48.0
420/85R38	144	A8/B	TL	R-1W	418	1679	40/50	160	2800	W15L	48.0
460/85R30	145	A8/B	TL	R-1W	455	1544	40/50	160	2900	DW15L	52.0
460/85R34	147	A8/B	TL	R-1W	455	1646	40/50	160	3075	W16L	52.0
460/85R38	149	A8/B	TL	R-1W	455	1747	40/50	160	3250	DW16L	52.0
460/85R38	151	A8/B	TL	R-1W	455	1747	40/50	240	3450	DW16L	52.0
520/85R38 (20.8R38)	155	A8/B	TL	R-1W	516	1849	40/50	160	3875	DW16L	54.0
520/85R38 (20.8R38)	163	A8/B	TL	R-1W	516	1849	40/50	240	4875	DW16L	54.0
520/85R38 (20.8R38)	169	A8/B	TL	R-1W	516	1849	40/50	360	5800	DW16L	54.0
520/85R42 (20.8R42)	157	A8/B	TL	R-1W	516	1951	40/50	160	4125	DW16L	54.0
520/85R42 (20.8R42)	162	A8/B	TL	R-1W	516	1951	40/50	240	4750	DW16L	54.0
650/85R38	173	A8/B	TL	R-1W	645	2071	40/50	240	6500	DW20B	61.0
480/80R38	149	A8/B	TL	R-1W	479	1733	40/50	160	3250	W15L	50.0
480/80R38	151	A8/B	TL	R-1W	479	1733	40/50	240	3450	W15L	50.0
480/80R42	151	A8/B	TL	R-1W	479	1835	40/50	160	3450	DW16L	52.0
480/80R46	152	A8/B	TL	R-1W	479	1936	40/50	160	3550	DW16L	52.0
480/80R46	158	A8/B	TL	R-1W	479	1936	40/50	240	4250	DW16L	52.0
480/80R50	159	A8/B	TL	R-1W	479	2038	40/50	160	4375	DW16L	52.0
620/75R26 (23.1R26)	166	A8/B	TL	R-1W	625	1590	40/50	320	5300	DW20B	55.0

AR100 Size	Load Index	Speed Rating	Type	Pattern Code	Section Width (mm)	Overall Diameter (mm)	Maximum Speed (km/h)	Inflation Pressure(kPa)	Maximum Load (kg)	Standard Rim	Tread Depth (mm)
9.5R24	107	A8/B	TL	AR100	240	1040	40/50	160	975	W8	33.0
9.5R24	112	A8/B	TL	AR100	240	1040	40/50	210	1120	W8	33.0
11.2R24	119	A8/B	TL	AR100	285	1095	40/50	210	1360	W10	35.0
11.2R28	116	A8/B	TL	AR100	285	1200	40/50	160	1250	W10	35.0
12.4R24	119	A8/B	TL	AR100	315	1145	40/50	160	1360	W11	36.0
13.6R24	114	A8/B	TL	AR100	345	1210	40/50	120	1180	W12	37.0
13.6R24	121	A8/B	TL	AR100	345	1210	40/50	160	1450	W12	37.0
13.6R24	124	A8/B	TL	AR100	345	1210	40/50	210	1600	W12	37.0
14.9R24	126	A8/B	TL	AR100	378	1245	40/50	160	1700	W13	38.0
14.9R24	130	A8/B	TL	AR100	378	1245	40/50	210	1900	W13	38.0
14.9R26	127	A8/B	TL	AR100	378	1316	40/50	160	1750	W13	38.0
14.9R26	132	A8/B	TL	AR100	378	1316	40/50	210	2000	W13	38.0
14.9R28	128	A8/B	TL	AR100	378	1350	40/50	160	1800	W13	38.0
14.9R28	133	A8/B	TL	AR100	378	1350	40/50	210	2060	W13	38.0
14.9R30	129	A8/B	TL	AR100	378	1418	40/50	160	1850	W13	38.0
14.9R30	134	A8/B	TL	AR100	378	1418	40/50	210	2120	W13	38.0
15R24	144	A8	TL	AR100	410	1330	40	280	2800	DW14L	31.0
15R24	148	A8	TL	AR100	410	1330	40	330	3150	DW14L	31.0
15R24	158	A6	TL	AR100	410	1330	30	450	4250	DW14L	31.0
15R24	162	A6	TL	AR100	410	1330	30	550	4750	DW14L	31.0
16.9R28	136	A8/B	TL	AR100	429	1420	40/50	160	2240	W15L	39.0
16.9R28	140	A8/B	TL	AR100	429	1420	40/50	210	2500	W15L	39.0
16.9R30	137	A8/B	TL	AR100	429	1475	40/50	160	2300	W15L	39.0
16.9R30	141	A8/B	TL	AR100	429	1475	40/50	210	2575	W15L	39.0
16.9R30	144	A8/B	TL	AR100	429	1475	40/50	250	2800	W15L	39.0
16.9R34	132	A8/B	TL	AR100	429	1587	40/50	120	2000	W15L	39.0
16.9R34	139	A8/B	TL	AR100	429	1587	40/50	160	2430	W15L	39.0
16.9R34	143	A8/B	TL	AR100	429	1587	40/50	210	2725	W15L	39.0
18.4R30	142	A8/B	TL	AR100	467	1545	40/50	160	2650	W16L	42.0
18.4R30	149	A8/B	TL	AR100	467	1545	40/50	240	3250	W16L	42.0
18.4R34	144	A8/B	TL	AR100	467	1645	40/50	160	2800	W16L	42.0
18.4R34	149	A8/B	TL	AR100	467	1645	40/50	210	3250	W16L	42.0
18.4R38	146	A8/B	TL	AR100	467	1750	40/50	160	3000	W16L	42.0
18.4R38	151	A8/B	TL	AR100	467	1750	40/50	210	3450	W16L	42.0
20.8R38	153	A8/B	TL	AR100	528	1835	40/50	160	3650	W18L	43.0
20.8R38	157	A8/B	TL	AR100	528	1835	40/50	210	4125	W18L	43.0

Related Tyre Knowledge

● Agricultural tyres are defined as tyres that are specifically used for agricultural machinery and are resistant to abrasion, punctures, high temperatures and other characteristics. According to the tyre carcass structure and purpose, agricultural tyres can be classified into agricultural radial tyres, agricultural bias tyres, agricultural implement tyres and agricultural construction machinery tyres. These tyres are designed to adapt to a variety of terrains, such as mud, sand, dry fields, paddy fields, etc., and are used on agricultural machinery, such as tractors, harvesters, etc.

● Agricultural radial tyres are also called wire tyres. These tyres generally have two or three layers of steel wire ring belt cross placed on the cord fabric carcass combination. Agricultural radial tyres are characterized by durability and puncture resistance, as well as high load capacity and good shock absorption. When the vehicle is in operation, this kind of tyre is not easy to appear deformation, so it can reduce fuel consumption to a certain extent, with good economy. In addition, its heat dissipation performance is also very good, more suitable for high temperature, high speed agricultural machinery use.
